Marine Aluminum Floating Dock Aluminum Alloy Float Pontoon WPC Decking

Basic Information
Place of Origin: China
Brand Name: kaishin
Minimum Order Quantity: 20 Square meter~200 Square meter
Price: 250 USD ~480 USD 1 Square meter
Packaging Details: Customer request
Delivery Time: 10~15 Word day
Payment Terms: L/C, T/T
Supply Ability: 200 Square meter 15 Word day
Place Of Origin: Guangdong, China Part: Floating Dock
Application: Floating Pontoon Length: Customers' Demand
Product Name: Durable Marine Ship Aluminium Floating Dock Material: Aluminum,WPC Decking,Float
Type: Durable Marine Ship Aluminium Floating Dock
High Light:

Marine Aluminum Floating Dock Durable

,

Marine Aluminum Float Pontoon

,

Aluminum Alloy Float Pontoon

Aluminum Alloy Floating Pontoon Dock

All our floating docks are custom-made, according to project requirements, and can have variable load and float ranges according to the specific need. The docks can be fitted with electrical or water systems and all accessories for the end users.

The name says it all: docks that float. As far as floating docks are concerned, there is no fixed height or level. These docks have several advantages over fixed docks.

The main structure of the frame construction consists of anti-coronal marine grade aluminum 6061-T6, welded together so as to obtain a solid supporting frame, completed by electrically isolated aluminum beams, on which the floors are made of exotic precious wood or WPC (Wood Plastic Composite).

Aluminum dock systems can be customized with various options and styles – decks and roofs and more. Aluminum floating docks are great for lakes and other freshwater applications.​We can assist you in planning your floating dock project and customizing your new aluminum dock system along with a great selection of dock accessories – dock bumper, dock cleats, dock ladders, etc.

Floating docks can be used as swim platforms, kayak and jet ski use, fishing, or other enjoyable waterfront activities.

We are able to manufacture any shape or height of aluminum floating dock, ensuring that each floating dock meets the optimum level of functionality for each specific install.

Freeboard 300mm-600mm Mainly depends on the weight & load & structure design.
Being controllable.
Lifespan 20-50 years Should be maintained periodically.
Floating dock specifications (The main part)
Items Details Remarks
Frame Aluminum Alloy Anti-corrosion; Durable; Strong yield strength; Light weight; Easy to install
Pontoon Box HDPE & EPS Foam Durable; Anti-corrosion; Anti-UV; Low-temperature toughness; Light to transport; Easy to maintain & install; 20 years lifespan
Decking panel Wood Plastic Composite (WPC) Various colors & sizes; Corrosion resistant; Mothproof; Low water absorption; Anti-UV; Easy to maintenance
Floating dock specifications (The accessories part)
Items Details Remarks
Gangway/ Ramp Aluminum Alloy Frame, Handrail, Decking Strong loading capability; Safe and stable; UV resistant; Long life span; Low maintenance cost;
Flexible movement (with rollers, can adjust according to water level)
Mooring Cleat Stainless Steel / Aluminium cast 2.5T-10T; Durable; Corrosion resistance and sturdy in a saltwater environment
Pile Cap LLDPE Cone UV Resistant; High-Stress Crack Resistance; Maintenance Free; Seamless Design
Pile Guide AISI-316
Nylon roller / Block
Easy operation and maintenance; Durable
Rubber Fender D-shape
Extrusion compound
Strong – No pull through; Protects – Shock Absorbing; Looks Great – No fading; Easy Install – Nail or screw; Economical – Saves Money
Water and Power Pedestal Aluminum material case, 2x 1/2 Water Tap, LED Lightning, RCD & MCB 16A/32A/ 63A; Supply electrical & water; Aluminium material case; Voltage 220V; 2x 1/2 Water Tap; LED Lightning; RCD & MCB
Fire Pedestal Stainless steel case, Fire extinguisher, Lifebuoy Compact design; Tempered Safety Glass; Longer life in outdoor applications; Sturdy surface resists chipping, peeling, and flaking
Corner Bumper Rubber / PVC Tough and tear-resistant; Provides maximum cushion; Protection for docks & hulls; Easily installation; WILL NOT mark or mar your hull
Other accessories Bolts&Screws,Rivet,Rubber Pad,etc. All connection or fixing fittings for each part are well designed and durable, especially for the marine environment.

Marine Aluminum Floating Dock Aluminum Alloy Float Pontoon WPC Decking 0

Marine Aluminum Floating Dock Aluminum Alloy Float Pontoon WPC Decking 1
Marine Aluminum Floating Dock Aluminum Alloy Float Pontoon WPC Decking 2

Shenzhen Kaishin Marine Accessories Co., Ltd, established in 2019, is a professional engaged in the sale and service of floating docks and dock accessories.

We are committed to producing competitive dock products and accessories for dock builders, marinas, yacht clubs, retailers, and individual consumers.

Marine Aluminum Floating Dock Aluminum Alloy Float Pontoon WPC Decking 3

Marine Aluminum Floating Dock Aluminum Alloy Float Pontoon WPC Decking 4

Marine Aluminum Floating Dock Aluminum Alloy Float Pontoon WPC Decking 5

No. FAQ Answers
1 How do I get an estimate? How do we get started? Please kindly send us an online quote request providing us with the drawing and details available, we are able to get back to you with a quotation.
2 Is the installation included with the purchase of a floating dock project? No. Installation is not included. However, installation instructions can be provided.
3 How do I know what type of installation is best for me, on my property? Every situation on every property is slightly different. We can provide a consultation to review your needs according to your local conditions.
If you decide to purchase a dock from us, the consulting fee will be waived and we can design a dock and land assembly plan tailored particularly for your specific property and waterfront.
